M10 Commuting Electric Scooter Bundle

Foldable, portable design for commuting.

Simple design, lightweight, easy to use.

(Contains 2 M10 commuting electric scooters).

Back in stock in early February.



Order Processing Time: Less than 5 business days

Shipping Time: 5–7 business days (US)

Ships from the US

• 18 Miles (29 km) Max Range
• 20 mph (32 km/h) Max Speed
• 7.5 Ah Battery Pack
• 10-Inch (25.4 cm) Inflatable Tires
• 220 lb (100 kg) Max Load
• 5-Hour Fast Charging
• Dual Braking Systems
• 2 W LED Headlight

Product Information	Unfolded Size	42.1 × 16.9 × 46.1 in (1070 × 430 × 1170 mm)
	Folded Size	42.1 × 16.9 × 15.5 in (1070 × 430 × 393 mm)
	Ground Clearance	4.1 in (105 mm)
	Product Weight	29.8 lb (13.5 kg)
	Adapter Input Voltage	100-240 V AC, 50/60 Hz
Drive System	Motor	36 V, 350 W
	Tire (Front & Rear)	10-inch inflatable tires
	Max Speed	20 mph (32 km/h)
	Max Range	18 miles (29 km)
	Max Climbing Capability	15°
	Load	44-220 lb (20-100 kg)
Functions	Foldable Stem	Yes
	Battery Pack	Non-detachable
	Brake System	Electronic braking system and rear disc brake
	Speed	3 settings
	Illumination	LED headlight + taillight
	Warning Function	Bell
	IP Rating	IP54
Operating Conditions	Operating Temperature	32 to 113°F (0 to 45°C)
	Storage Temperature	-4 to 140°F (-20 to 60°C)

Battery Specifications

Type	Li-ion
Charging Time	5 hours
Voltage	36 V
Capacity	7.5 Ah, 270 Wh
Operating Temperature	32 to 113°F (0 to 45°C)
Charging Temperature	32 to 113°F (0 to 45°C)
Max Charging Voltage/Current	42 V, 2 A
Storage Temperature	-4 to 113°F (-20 to 45°C)
Storage Time	3 months (on a full charge)

Charger Specifications

Model	CP4215
Input	100-240 V AC, 50/60 Hz
Output	42.3 ± 0.3 V, 1.4-1.6 A

No.	Parts	Quantity
1	Folding Electric Scooter	2
2	Charging Adapter	2
3	Handlebars	4
4	Brake Lever	2
5	M6 Hexagon Wrench	2
6	User Manual	2
7	After-Sale Card	2

*For your best X7 Pro riding experience, we recommend inflating its tires to 31.9-34.8 psi (220-240 kPa) BEFORE the first ride.

Q: How to ride the electric scooter?

1. Wear protective gear such as a helmet.
2. Press the power button once to turn on the scooter.
3. Place one foot on the middle of the deck and use the other foot to build up some momentum.
4. Gently press down the throttle to accelerate.
5. Squeeze the brake lever to brake.



Q: How to assemble the electric scooter?

1. Unfold the scooter by pulling upon the stem from the rear fender.
2. Screw the locking latch clockwise using a wrench until it is fixed in place.
3. Screw the brake lever using an Allen wrench.
4. Rotate the left handle clockwise until it is fixed in place. Rotate the right handle counterclockwise until it is fixed in place.



Q: How to unfold the electric scooter?

1. Lift the handlebar up slightly and slide it out of the locking hook until it is detached from the locking hook on the rear fender.
2. Place a foot on the anti skid deck and push the stem into the upright position. You should hear a “click”.
3. Secure the handlebar by rotating the stem safety latch clockwise.



Q: How to fold the electric scooter?

1. Release the stem safety latch by rotating it counterclockwise.
2. Press the folding spanner and lower the stem.
3. Align the locking latch with the side of the locking hook.
4. Lock the stem with the locking hook.



Q: How to charge the battery?

1. Remove the charging port cover at the bottom of the stem. Make sure the charging port is dry and free of dust.
2. Connect the charging adapter.
3. The battery is fully charged when the indicator light of the charging adapter turns from red to green.
4. Close the charging port cover after charging the battery.



Q: How to maintain the electric scooter?

1. Make sure the scooter is turned off and the power adapter is disconnected.
2. Wipe clean the scooter with a damp cloth. Never use lubricating oil on the body and do not immerse it in water.



Q: How to store the electric scooter?

1. Fully charge the scooter before storing, and charge it at least once a month to prevent premature decay of the battery capacity.
2. Do not charge if the temperature is below 50°F (10°C).
3. Keep the scooter in a dry, ventilated, and cool area away from direct sunlight, rain, and high humidity, and cover the scooter to protect it from dust.
